3U VPX SOSA Aligned 4-Channel A/D and D/A Board based on the Intel® Agilex® 9 Direct RF Series (DRF5580)

Product Documents

In stock

SKU: DRF5580 Category:

Description

The DRF5580 is a high-performance, SOSA™ aligned 3U Open VPX board based on the Intel Agilex 9 Direct RF-Series. Four 64 GSPS A/D and D/A converters are integrated into the Agilex 9’s multiprocessor architecture, creating a multichannel data conversion and processing solution on a single chip. The DRF5580 brings Agilex 9 performance to 3U
VPX with a complete system on a board. Complementing the Agilex 9’s on-chip resources are the DRF5580’s sophisticated clocking section for multichannel and multiboard synchronization, a modular front end for RF input and output, 16 GBytes of DDR4, a 10 GigE interface, a 40 GigE interface, a gigabit serial optical interface capable of supporting dual 100 GigE connections and general-purpose serial and parallel signal paths to the FPGA.

Features

  • Developed in alignment with the SOSA™ Technical Standard
  • Incorporates Intel Agilex 9 Direct RF AGRW014
  • 16 GB of DDR4 SDRAM
  • 10 GigE Interface
  • 40 GigE Interface
  • Optional VITA 67.3C optical interface for gigabit serial communication
  • Dual 100 GigE UDP interface
  • Compatible with several VITA standards including: VITA 46, VITA 48, VITA 67.3C, and VITA 65 (OpenVPX™ System Specification)
  • Ruggedized and conduction-cooled
  • Unique system-on-module design enables migration to other form factors
  • Board Support Package (BSP) for software development
  • FPGA Design Kit (FDK) for custom IP development
